| Specifications: |
| Cutaway. |
| Body width: 370 mm. |
| Body length: 470 mm. |
| Body depth: 50 mm. |
| Scale length: 630 mm. |
| Hand carved spruce top. |
| Maple back & sides. |
| Single-bound top with single-bound f-holes. |
| Single-bound back. |
| Mahogany neck with adjustable truss rod. |
| Metal truss rod cover. |
| Single-bound headstock with mother-of-pearl inlay. |
| Single-bound rosewood fingerboard with mother-of-pearl block inlay. |
| Open back tuners. |
| Metal neck plate (except on early examples). |
| 2 DeArmond Dynasonic pickups. |
| Hagström Tremar vibrato tailpiece and Hagström bridge. |
| Nickel plated hardware. |
| Black or red finish. |
|
| Introduced: Circa 1963 |
|
| Earliest known example: 432925 (1963) |
| 439926 (1964) |
| 439882 (1964) - refinished, changed tuners) |
| 439922 (1964) - (changed tuners and truss rod cover, missing pickguard) |
| 441677 (1964) |
| 444492 (1964) |
| 445044 (1964) |
| 451379 (1965) - (changed tuners, missing pickguard) |
| 451388 (1965) |
|
| Circa 1966: |
| Changed tailpiece and bridge supplier. |
|
| 469888 (1966) - (changed truss rod cover) |
| 470256 (1966) - (changed bridge) |
| Latest known example: 470680 (1966) |
|
