| Specifications: |
| Non-cutaway. |
| Goliath size: |
| Body width: 400 mm. |
| Body length: 505 mm. |
| Body depth: 95/120 mm. |
| Fingerboard width: 43 mm. |
| Scale length: 630 mm. |
| Spruce top with X-bracing. |
| Flame maple back & sides. |
| 4-ply bound top. |
| Single-bound back. |
| Mahogany bolt-on neck |
| with adjustable truss rod. |
| Single-bound rosewood fingerboard with bass side pearl dot inlay. |
| Rosewood bridge. |
| Nickel plated strip tuners with white plastic buttons. |
| Sunburst finish. |
| Ten year warranty. |
|
| Marketed by U.K. distributors as Goliath Model 1795 and |
| Goliath Electric Model 1890 (w/DeArmond pickup and controls). |
|
| Introduced: Circa 1963 |
| as a replacement for LM 26. |
|
| Circa 1964: |
| Nickel plated individual Van Gent tuners with metal buttons. |
| Also available as Goya N-26. |
|
| Earliest known example: 450366 (1965) |
| 450373 (1965) - (changed tuners) |
| 450381 (1965) - (refinished natural) |
| 454752 (1965) |
|
| Circa 1965: |
| Belly bridge with individual height adjustable plastic bridge saddles. |
| (Old style bridge still used in early 1967). |
|
| 459813 (1966) |
| 474383 (1966) - (refinished body) |
| 478052 (1967) |
| 484064 (1967) |
| 488263 (1968) |
| 488307 (1968) |
| 494170 (1969) |
| 497060 (1969) |
| Latest known example: 504201 (1970) |
|
| Circa 1970: |
| Replaced by Model 163. |
|
