| Specifications: |
| 12-string. |
| Non-cutaway. |
| Body width: 400 mm. |
| Body length: 505 mm. |
| Body depth: 95/120 mm. |
| Fingerboard width: 49 mm. |
| Scale length: 630 mm. |
| Spruce top with undetermined bracing. |
| Flame maple back & sides. |
| 4-ply bound top. |
| Single-bound back. |
| Mahogany bolt-on neck |
| with adjustable truss rod. |
| Metal truss rod cover. |
| Single-bound headstock with mother-of-pearl inlay. |
| Single-bound ebony fingerboard with bass side pearl block inlay. |
| Rosewood bridge with six bridge pins and six individual height adjustable plastic saddles. |
| Chrome plated individual tuners. |
| Natural finish. |
| Ten year warranty. |
|
| Introduced: Circa 1971 |
|
| Earliest known example: 512696 (1971) |
| 512760 (1971) - (Goya TS-5 neck) |
| 512776 (1971) |
|
| Circa 1972: |
| Bridge with 12 bridge pins and a single bone saddle. |
|
| 520660 (1972) |
|
| Circa 1972: |
| Double-herringbone rosette. |
| Changed pickguard shape. |
|
| Latest known example: 520670 (1972) |
|
