| Specifications: |
| Levin version of Goya TS-5. |
|
| 12-string. |
| Non-cutaway. |
| Goliath size: |
| Body width: 400 mm. |
| Body length: 505 mm. |
| Body depth: 95/120 mm. |
| Fingerboard width: 51 mm. |
| Scale length: 630 mm. |
| Spruce top with ladder bracing. |
| Flame maple back & sides. |
| 4-ply bound top. |
| Single-bound back. |
| Mahogany bolt-on neck |
| with adjustable truss rod. |
| Single-bound rosewood fingerboard with centered pearl dots. |
| Rosewood bridge. |
| Nickel plated tuners with white plastic buttons. |
| Natural finish. |
| One year warranty. |
|
| Marketed by Rose-Morris in U.K. as Goliath 12-string Model 1844. |
|
| Introduced: Circa 1963 |
|
| Earliest known example: 440191 (1964) |
| 4416xx (1964) |
| 441635 (1964) - (changed truss rod cover) |
|
| Circa 1964: |
| Bass side fingerboard dot inlay. |
|
| 450474 (1965) - (reused Model 55 label) |
| 454001 (1965) |
| 458150 (1965) |
| 459281 (1966) |
| 461343 (1966) |
| 462881 (1966) |
|
| Circa 1966: |
| Chrome plated tuners with metal buttons. |
|
| Circa 1969: |
| Body meets neck at the 14th fret. |
| Five year warranty. |
|
| 493045 (1969) |
|
| Circa 1969: |
| Belly pin bridge with six pins and six individual height adjustable plastic bridge saddles. |
|
| Circa 1970: |
| Set neck. |
| Pickguard. |
|
| 4177024 (Circa 1970) - (Goya serial number, 12 fret neck) |
| Latest known example: 4177037 (Circa 1970) - (Goya serial number, 12 fret neck) |
|
