| Specifications: |
| Non-cutaway. |
| Body width: 315 mm. |
| Body length: 460 mm. |
| Body depth: 78 mm. |
| Spruce top with ladder bracing. |
| Birch back & sides. |
| Triple wood bound top with white outer edge. |
| Unbound back. |
| Unbound headstock. |
| Unbound ebonized fingerboard with mother-of-pearl dot inlay. |
| Silver plated frets. |
| Pyramid bridge. |
| Bridge pins and strap button with mother-of-pearl inlay. |
| Mahogany finished back & sides. |
| Natural finished top. |
|
| Introduced: Circa 1900 |
|
| Circa 1906: |
| Body depth: 90 mm. |
| Triple wood bound top. |
| Unbound walnut fingerboard with mother-of-pearl inlay. |
| Nickel plated tuners. |
| Also available with tailpiece. |
|
| Earliest known example: 7526 (1907) |
| Latest known example: 40617 (1918) |
|
| Circa 1923: |
| Multiple-bound top. |
| Also available in Concert size: |
| Body width: 340 mm. |
| Body length: 493 mm. |
| Body depth: 90-95 mm. |
| Also available in Harp size: |
| Body width: 375 mm. |
| Body length: 512 mm. |
| Body depth: 110 mm. |
| Also available in Concert size as 10-string Bass Guitar (Model 27 ½). |
| Also available in Harp size as 12-string Bass Guitar (Model 29 ½). |
|
| Circa 1925: |
| Replaced by Model 6 C. |
|
